Ruijie Reyee RG-RAP72Pro Installation Manual page 13

RG-RAP72Pro Installation Guide
Power Step
Dimensions (W X D
X H)
Net Weight
Service Ports
Management Port
Status LED
Power Supply
Options
Max. Power
Consumption
Temperature
Humidity
Certification
MTBF
Warning
Operation of this equipment in a residential environment could cause radio interference.
5150 to 5350 MHz, EIRP ≤ 23 dBm
○
5470 to 5725 MHz, EIRP ≤ 30 dBm
○
5725 to 5825 MHz, EIRP ≤ 30 dBm
○
Indonesia:
2400 to 2483.5 MHz, EIRP ≤ 27 dBm
○
5150 to 5350 MHz, EIRP ≤ 23 dBm
○
5725 to 5825 MHz, EIRP ≤ 23 dBm
○
Egypt:
2400 to 2483.5 MHz, EIRP ≤ 20 dBm
○
5150 to 5350 MHz, EIRP ≤ 23 dBm
○
1 dBm
208 mm x 208 mm x 40 mm (8.19 in. x 8.19 in. x 1.57 in.) (excluding the mounting
bracket)
Main Unit: ≤ 0.65 kg (1.43 lbs.)
1 x 100/1000/2.5GBASE-T Ethernet port with auto-negotiation, support PoE input
1 x 100/1000BASE-T Ethernet port with auto-negotiation
NA
1 x status LED (blue)
DC power adapter: Local power supply at 12 V/2.5 A
Standard PoE: 802.3at-compliant PoE
< 30 W
Working temperature: 0° C to 40° C (32° F to 104° F)
Storage temperature: –40° C to +70° C (–40° F to +158° F)
Working humidity: 5% RH to 95% RH (non-condensing)
Storage humidity: 5% RH to 95% RH (non-condensing)
CE, RoHS, FCC, ISED, cTUVus
> 400000 hours
6
Overview
