Omtech POLAR+ User Manual page 29

Button Function
Diagnose
Key Lock
Jog setting
Laser setting
System info
Definition
Displays the hardware IO port information of the system.
U p o n e n t e r i n g t h e i n t e r f a c e , t h e s y s t e m h a r d w a r e
information is read.
Locks the home interface.
In the locked home interface, parameters such as Current
Processing File Name, Processing Progress, Processing
Time, etc., will be displayed normally, but only unlocking
operations can be performed.
Upon successful unlocking, it will jump to the normal home
interface. If unlocking fails, it will return to the locked home
interface.
Sets the Jog mode between Jog and Continuous.
• When the Jog mode is set to Jog, each press of the
direction key will move the corresponding axis once, with
the distance equal to the step length.
• When the Jog mode is set to Continuous, the step
length parameter is not effective. Pressing the direction
key will move the axis, and releasing the direction key
will stop the axis.
Sets the laser mode between Pulse and CW (continuous
wave).
• When the laser mode is set to Pulse, each press of the
Start key will emit laser once, with the laser duration set
by the user as the Laser time value.
• When the laser mode is set to Continuous, pressing the
Start key will keep the laser on, and releasing the Start
key will turn off the laser.
Shows the system information.
22
