5.1 Interlock

Because of the risk of blindness, burns, and other injury from direct exposure to the invisible
engraving beam, this device shuts off the laser automatically when parts of its protective housing
are opened.
Always make sure the path is clear between the laser and its target.
Never allow foreign objects between the laser and the material being engraved.
Take care not to leave any part of your body in the laser path when it is in
operation.

5.1.1 Cover Shutoff

You should test that the cover shutoffs activate properly before conducting any other work on your
machine.
1. Turn off the engraver.
2. Place a piece of laserable scrap material onto the workbed and then close the cover.
3. Turn on the engraver and duct fan.
Confirm that the cooling system, air assist, and exhaust fan have been activated.
4. Create or load a simple design into RDWorks.
5. Insert and turn the laser key.
6. Begin engraving by clicking Start in the software or pressing the Start button on the engraver.
7. Taking care not to expose yourself to seeing or being hit by any possible reflected laser light,
open the cover as little as possible.
