6.3.3 Uninstalling Your Rotary Axis

1. Gently move the laser tube and X-axis rail
forward.
2. Flip the rotary switch up to Standard to
activate the Y axis motors and control
signals.
3. Disconnect the rotary cable from the rotary
aviation socket and then cap the socket.
4. Release the tray interlock switch into the
open position by sliding the metal bracket to
the left.
X-Axis Rail
70
