Menu Interface - Omtech POLAR+ User Manual

3 Components

3.4.2 Menu Interface

Button Function
IP
Language
Restore PRM
Backup PRM
Definition
Sets the IP.
When entering the interface, the current IP address of the
board will be read.
When touching the dialog box for the IP address, a small
keyboard will pop up. Users can modify the host IP address
using the keyboard. Once the input is complete, click OK.
Sets the language.
When entering the interface, the gray box represents the
currently used language. Select the desired language to
switch to, click OK, and the home interface will pop up with
the selected language switched.
Restores the values of Jog Mode, step length, Pulse Mode,
and Laser Time.
Backups the values of Jog Mode, step length, Pulse Mode,
and Laser Time.
21
