CAUTION: Surfaces that are still hot
can be damaged if they come into contact
with cold water or a damp cloth. Never use
abrasive, corrosive or chlorine based cleaning
products. Never use steel or plastic scouring
pads. Never leave deposits of acid or alkaline
substances (vinegar, salt, lemon juice etc.) on
the appliance. Stainless steel or enamelled
surfaces must be cleaned only with water and
soap or a neutral detergent, thoroughly rinse
and dry. Use clean sponges or cloths to clean.
Injectors
WARNING: Cleaning or replacing
gas injectors must only be performed
by authorised and qualified gas service
engineers.
Burner Injector
(mm)
Auxiliary 0.50
47mm
Semi-Rapid 0.67
Rapid 0.75

9.4 Dometic mini grill

Use the appliance only in a well ventilated
space.
The ventilation openings must remain open
when the appliances are operating.
Ignition of the appliance
1. Manual ignition: oven - grill
f. Push in control knob, slightly turn to ignition
position, light burner with match or lighter
and keep knob pushed for 5 - 10 sec.
g. Release knob and turn it lo required position.
2. Automatic ignition: oven - grill
a. For igniting oven or grill, open oven door
completely
b. Push In control knob, slightly turn to ignition
position keeping it pushed in for 5 - 10sec.
c. Release knob and turn it to designed
position.
Note: Oven and grill burners will not light, if
door is not completely open.
3. Ignition of appliances with thermostat
Proceed according to paragraphs 1 and 2, with
or without electronic ignition. The ignition
position is obtained by turning control knob on
a position between 1 and 6 for the oven and grill
position (see symbol ▾ ▾ ▾ ▾)
For ovens with thermostat the different
positions of the knob correspond to the
following temperatures in °C of the oven.
Stanped N.
POS
TEMP
50
WARNING: If ignition is unsuccessful,
repeat operation from beginning; if necessary
67
have the appliance checked if a gas and/or
electricity failure in the appliance. If appliance
75
absolutely does not work, close gas inlet tap
and contact retailer. Before using oven for the
first lime, let it run at maximum temperature
for the duration of 20 mins without foodstuffs
inside:
WARNING: Use gloves when handling hot
elements!
In the event of the burner flames being
accidentally extinguished, turn off the burner
control and do not attempt re-ignite the burner
for at least 1 min.
Operation of the grill
a. Pull out heat protection plate
b. Light grill burner.
c. Keep oven door half-open
d. Do not use for more then 20 minutes.
Use of the rotisserie
Insert dripping-pan with the rotisserie installed
as indicated in (fig 5a). Push in the appropriate
button (fig 4a) in order to set going the rotisserie
motor.
Use of the Grill
a. Slide out heat protection plate.
b. Light grill burner
c. Keep oven door in half-open position.
1 2 3 4
130 160 180 200
5 6
220 240
