Swift MONZA CAMPERVAN Owner's Manual page 81

Fault
Communications
not working
Technical Support
If you require technical support on Sargent products then please visit the Support Customer Support
site at https://sargent.zohodesk.eu/portal/en/home In the Knowledge Base you can view product
documentation and search frequently asked questions and in the Ticket section you can raise a ticket
to request help from the support team.
Updates
From time to time there may be updates to the system firmware; these updates will be done at
service intervals by your dealership.
Technical Data & Approvals
Equipment – MC100, MC200, EC940
Outline Specification
Outline Specification – MC200
INPUT 230V
OUTPUT 230V
Outline Specification – MC100
VEHICLE &
LEISURE Inputs
CHARGER Input
OUTPUTS
INPUTS (Signals)
TMP Input
FRESH & WASTE
Inputs
80
Possible Cause Proposed Fix
Bluetooth not Using System Settings menu, select Bluetooth Pair
paired option.
Bluetooth not Ensure that the handheld device has Bluetooth
active on Device switched on and that the device supports the
Bluetooth 4 standard (BLE).
Bluetooth out of Ensure the handheld device is within 7M of the
range middle of the campervan.
230 Volts / 0 to 16 Amps
RCD protected, 2 x MCB outputs of 10A & 1 x MCB
output of 16A
Separate switched channels for heating system
and charger
2 x 20A battery inputs via 2 x 2-way connectors
1 x Dedicated battery charger input capable
of supporting up to 25A charger via a 2-way
connector
25A total output via multiple switched channels
protected by 8 fused outputs
Engine running, plus multiple vehicle
connections
1 x Temperature sensor
4 x Fresh water level, 4 x Waste water level
+ / - 10%
Check the charger
rating plate to ensure
the maximum current
is <= 25A
Fresh water negative
sensed
Waste water negative
sensed
