12 Volt DC Fuses
WARNING: When replacing fuses always replace a fuse with the correct value. NEVER replace
with a higher value / rating as this could damage the wiring harness. If a replacement fuse 'blows'
do not keep replacing the fuse as you could damage the wiring harness. Please investigate the
fault and contact your dealer.
The following table shows the fuse allocation for the 13 fuses fitted to the PSU. Please note that
fuses are dependant on PSU versions, so not all fuses may be present.
Fuse Rating
1 25 Amps
2 10 Amps
3 10 Amps
4 7.5 Amps
5 7.5 Amps
6 7.5 Amps
7 7.5 Amps
8 7.5 Amps
9 10 Amps
Note: Fuses (2-9) have a Red LED below them which provides indication that the fuse has
i
blown. The following table shows details of the recommended fuse(s) located at each battery.
Fuse Rating
Leisure 40 Amps
Battery 1
Vehicle 40 Amps
Battery
Fuse Colour
White
Red
Red
Brown
Brown
Brown
Brown
Brown
Red
Fuse Colour
Orange
Orange
Description
Charger
12V Sockets / USB Sockets
Main Lighting
Auxiliary / Awning Lighting
Filler Pump
Pump
Dimmable Lighting
Permanent (Unswitched)
Compressor Fridge (Permanent
Switched)
Description
Fuse remotely located near battery1
Fuse remotely located in supply from
vehicle battery
