Swift MONZA CAMPERVAN Owner's Manual page 73

Warning
Fresh water level low
Leisure battery low
Leisure battery very low
Leisure battery high
Vehicle battery warnings
Engine running
Mains lead (hook-up cable)
still connected / plugged in
72
When
With pump turned on and fresh
water level low (less than 25%
full)
Only available when an on-
board tank is fitted
With control panel power on
and leisure battery selected
(as active battery) and the
charge level falls below:-
Lead Acid: 11V
AGM: 11V
Lithium: 12V
With control panel power on
and leisure battery selected
(as active battery) and the
charge level is below:-
Lead Acid: 10V
AGM: 10V
Lithium: 11V
Note: This is an emergency cut off level to protect the
i
battery from severe damage. You should not rely on this cut
off level during normal operation, but manage your power
consumption to a discharge level of 11.5V or above.
This cut off only applies to power drawn from the battery by
the leisure equipment that is controlled by the control panel
power switch; it will not protect the battery from discharge by
permanently connected equipment.
With control panel power on
or off and leisure battery is
selected (as active battery)
and the voltage level rises
above 15.4V
If the vehicle battery is selected instead of the leisure battery,
then similar warnings to those described above are applied to
the vehicle battery. The vehicle battery low warning level is
10.9V
When the engine is started the
system power will be turned
off
When the engine is started
and the mains cable is still
plugged in and the charger is
switched on
Type
Message on screen and 60
second audible beep
Message on screen and 60
second audible beep.
Message on screen and 60
second audible beep. If no
action taken after 30 seconds,
then the system will switch the
power off to prevent severe
discharge of the battery
Message on screen and
repeated beeps from the
control panel. The power is
automatically turned off. The
beeping will not stop until the
fault is cleared.
Message on screen stating
'engine running'.
Message on screen and
repeated beeps from the
control panel. The beeping
will not stop until the hook-up
lead is removed.
