Outline Specification
2 x Momentary switch inputs
SWITCH Inputs
2 x CANBus Data communication & Power for
DATA In / Out
Control Panel and other CAN accessories
IP rating IP31
Ambient 0 to 35° Celsius
Operating
temperature
Dimensions
Overall size (HxWxD) 180 x 166 x 75mm
MC100 Mains Unit
Clearances 75mm above, 50mm left & right
Overall size (HxWxD) 190 x 166 x 95mm
MC200 Control Unit
Clearances 75mm above, 50mm left & right
Overall size (HxWxD) 94 x 94 x 26mm
EC940 Control
Cut-out size (HxW) 86 x 86mm
Panel
Overall size (HxWxD) 35 x 20 x 36mm
Temp / Humidity
Cut-out size (HxW) 26 x 14mm
Sensor
Approvals
Power Supply Unit: Automotive Electro Magnetic Compatibility (EMC) to ECE Reg10.06, Type
approval number E11 10 R 06 12228
Control Panel: Automotive Electro Magnetic Compatibility (EMC) to ECE Reg10.06, Type approval
number E11 10 R 06 12231
System: BSEN 1648-1, BSEN1648-2 compliant, BS7671: 2018 compliant
Residual Current Device: RCD 40A 30mA trip to BS EN 61008
Miniature Circuit Breakers: MCB's type C 6000A breaking capacity to BSEN 60898
Integrated Charger: BS EN 60335-1/2.29, 2006/95EC, IEC61000-3.2/3:1995, 1.
Low Voltage Directive: 2006/95EC TUV-014900-A1, EN55022, Class B, EN55024/ Level 2
Declaration of Conformity
Equipment: Leisure Power Control System
Model name(s): MC100, MC200, EC940
I hereby declare that the equipment named above has been designed to comply with the relevant
sections of the above referenced approvals. The unit complies with all essential requirements of the
Directives.
Whilst every effort has been made to ensure the accuracy and completeness of this document, no guarantee is given against errors
or omissions. This document may be updated / improved over time therefore please check with your dealer / supplier for update
information or visit www.sargentltd.co.uk
Automatic shutdown
and restart if
overheated /
overloaded
Weight 0.71 Kg
Weight 1.24 Kg
Fixing via hidden
spring clips
Weight 135g
