9.11 Rock and roll rear bed

Setting up the Folding rear seat into a bed
Before folding the bed out, slide the bench seat
into the correct position which is just rear of the
C-pillar (rear of the sliding door) Lift the front
bar handle and pull or push in the direction
required. Let go of the handle and the seat will
click into the lockable traveling position.
Folding the bench seat
Standing facing the seat. Pull the seat base up
and forward.
Rotate the front seat base forward revealing the
release handle to the right hand side inside the
frame.
The Back rest then folds forward. To lower the
back rest release the handle on the right and the
back rest can be gently lowered down.
Kneeling on the folded seat lower the rear of the
bed with the loose mattress.
When returning the bed into the traveling seats
ensure the seat belt sockets are lifted high
before the seat base is folded into position.
99
