• Pull the roof down carefully using the central
strap or the roof handles at each side together,
ensuring the tent fabric will not be jammed in
this process.
Note: Make sure that the tent fabric will not
i
be jammed in this process.
Note: The roof should be pulled down
i
evenly and not twisted as this may cause
damaged to the hinges.
• Fold up the remaining tent fabric thoroughly
in the front area and fix using the three Velcro
98 fasteners.
• After that, the roof should be locked according
to the following steps:
∘ Fold-the tent fabric up thoroughly in the area
of the locking mechanism. Hook the locking
bar in to the side retaining bracket to secure
the catch (if it is tight pull down on the roof
handle to help)
∘ On the locking mechanism push the main
handle up to lock the catch and secure the
roof.
These steps must always be executed at the
driver's side as well as the passenger's side.
Note: Make sure that the tent fabric is not
i
jammed in this process.
• Close the Click-Lock of the roof (driver's side
as well as passenger's side) to ensure the
locking mechanism cannot pull free.
• Close the access hatch cover and fasten using
the x5 stud fasteners across the front of the
hatch opening. Any parts that are projecting
from the opening can be accommodated in
the cavity between the elevating roof and the
access cover.
