6. Remove the tire valve dust cap and attach the
tire inflation pipe.
7. 12V Plug the 12 V DC pov.•er point connector
into the 12 V DC socket).
8. Start the engine an switch the compressor on.
9. Inflate the tire to the recommerded tire
pressure shown on the Tire Label on the B
pillar. Do not operate the compressor for
more than 15 minutes continuously. Switch
the compressor and the ignition off and check
the current tire pressure with the pressure
gauge.
32
Note: If the recommended tire pressure
i
is not reached within 75 minutes. you may
disconnect the compressor. slowly roll the
vehicle forward by one car length to distribute
the sealant within the tire, then restart
the inflation process. If the recommended
inflation pressure is still not reached. the tire
could be damaged beyond a temporary repair.
Stop and call roadside assistance.
10. Remove the power plug from the 12 V DC
power potnt connector.
11. Unscrew the pipe from the tire valve and put
the protective cap back in place. Replace the
valve cap on the tire valve.
Note: Some residual sealant fluid tnay
i
drip or briefly spray out the pipe while you
disconnect it. This is normal.
12. Do not remove the sealant bottle from the
compressor. This avoids leakage of residual
sealant.
13. Remove the warning label showing the
maximum permissible speed 80 km/h (50
mph) from the side of the compressor and
place it on top of the instrument panel or
the center of the dash in the driver's field of
view. Make sure the label does not obscure
anything important.
14. Store the kit. the bottle lid and cap safely in
your vehicle. You need the kit again when
you check the tire pressure after driving the
vehicle a short distance.
