11.4 Campervan Towing Capabilities

Model MTPLM
MONZA S 3115kg
Manual Gear
Box
MONZA S Auto 3175kg
Gear Box
Please note that the additional weight of the tow
bar and trailer nose weight increases the rear
axle loading of the motor home so care should
be taken that the rear axle load is not exceeded
when towing.
To ensure adequate road holding, the load on the
front axle, under all conditions, must not be less
than 40% or more than 70% of the total weight.
Care must be taken when distributing loads. The
loadings and weights above are maximums and
must not be exceeded under any circumstances.
CAUTION: When fitting a towbar, it must
meet certain minimum requirements as
specified by Type Approval Regulations.
The bar will have marked on it the approval
standard (94/20/EC or 55R ECE) and the
maximum download, or noseweight, that it can
accept. It must fit the manufacturer's approved
mounting points and must not obscure the
towing vehicle's number plate.

11.5 Jacking Points

For Jacking points refer to Ford handbook.
https://www.ford.co.uk/support/owner-
manuals?ref=%2F
Permissible Permissible
Front Axle Rear Axle
Load Load
1650kg 1675kg
1650kg 1700kg
To ensure adequate road holding, the load on the
front axle, under all conditions must be not less
than 40% or more than 70% of the total weight.
Care must be taken when distributing loads. The
loadings above are maximum loadings and must
not be exceeded under any circumstances.
Recommended
Gross Train
Maximum Trailer
Weight
Weight
2500kg 5615kg
2500kg 5675kg
