Waste water system
1. The waste water holding tank is secured
under the rear of the vehicle, and is gravity
fed.
2. In order to eliminate unpleasant odours as
much as possible, only smooth bore pipes
are used.
Should the waste water tank be overfilled, it is
possible that waste water will backfill the pipes
until it eventually appears in the kitchen bowl.
In order to prevent this, please monitor the
water level.
The waste water tank (the forward most water
tank of the two under the rear of the vehicle) is
fitted with a grey drain valve. Make sure to close
the drain valve of the waste tank after emptying
the tank to prevent waste water from draining
from the tank accidentally.

7.5 Fresh water system

1. All fittings, including the holding tank, water
pipes, taps and connections are of food
quality material (to BS6920) and therefore,
should not affect the quality of the water
used. It is recommended however, that the
system is flushed through twice before it is
used for the first time, and always cleaned/
flushed after it has stood unused for a period
of time (eg over the winter period). Care has
been taken (using smooth bore pipes etc) to
eliminate as many water traps as possible.
2. When filling the fresh water system
remember to check that the water source
is suitable for use as drinking water and, if
you are using a hose pipe or water carrier,
that it is also made from nontoxic materials
(preferably food quality material).
3. The fresh water tank is fitted with a manual
drain valve on the tank, which will drain the
contents of the fresh water tank.
CAUTION: If the fresh water tank is
completely empty the pump will be unable
to pressurise the system and will operate
continuously. In this situation it is essential
that, in order to avoid damage to the pump, it is
switched off using the pump isolator switch on
the control panel until such time as the water
tank has been filled.
