7 Technical Data

7 Technical Data
Measuring
Range
Power Input
Power
Consumption
4 - 20 (safety function) three relay output
Signal Output
(safety function)
Temperature
Detector
Range
Temperature
Calibration Cap
Range
Drift Zero Drift
Drift Gain Drift
Response Time t50 with Environmental Guard
Response Time t90 with Environmental Guard
Noise
Humidity
Sensor Life
In-Rush Current
Physical
Length
Characteristics
Physical
Weight
Characteristics
Physical
Material Type
Characteristics
Pressure
Ingress
Protection
36
: 0 - 100% LEL
: 24 VDC ± 20% PELV/SELV
: < 6.0 W
3-wire current source One is fault relay; two gas alarm
:
relay (0.5 A at 30 VAC)
: –40 to +75 °C
: –30 to +60 °C
: < 1% LEL/ 3 months
: < 2% LEL/ 3 months
: < 7 sec
: < 15 sec
: < 1% FS
: 15 to 95% RH, non-condensing
: (→ 1.4 MSA Permanent Instrument
: < 350 mA
: 320 mm
2.5 kg (Aluminum)
:
3.5 kg (316 SS)
: Aluminum and 316 Stainless Steel
: 600 - 900 mmHg (80 - 120 kPa)
: IP66/ IP67
Warranty)
