13. ABSOCODER SENSOR CHECK LIST

●Applicable ABSOCODER sensor models
VLS-[ ]PW
VLS-[ ] PY
●Connection configuration
ABSOCODER
sensor
VLS-[ ]PW
VLS-[ ]PY
Checks at Point B should be carried out with Point A connected.
● Connector pin position and standard coil resistance ranges (at 25℃)
Connector Signal
pin No. name
1 SIN+
2 SIN-
3 -COS+
4 -COS-
5 OUT1+
6 OUT1-
7 OUT2+
8 OUT2-
9 Shield
－ －
The above standard coil resistance ranges are referential data to assist wiring disconnection diagnosis and are not
product specification values. There may be no wiring disconnection even when the resistance measurement is out
of the standard resistance range.
Extension sensor
Wiring color
VLS-256PWB
VLS-512PYB
Brown
46 to 66
Red
Orange
46 to 66
Yellow
Green
24 to 32
Blue
Violet
24 to 32
Gray
Shield
－
－
●Connector appearance and pin
position
NCW-3DNIP
Standard coil resistance [Ω]
VLS-512PWB
VLS-1024PYB
90 to 125
90 to 125
27 to 35
27 to 35
－
87
View A
A
B
View B
VLS-1024PW
VLS-2048PY
141 to 181
141 to 181
27 to 37
27 to 37
－
