11-4. CIP Extended Status Code

Status Codes may be present in the General Status and the Extended Status of an Error Response message.

11-4-1. Connection Manager Object Instance Extended Status Code

The error codes are returned with the response to a Connection Manager Service Request that resulted in an
error. These error codes shall be used to help diagnose the problem with a Service Request. The error code shall
be split into an 8 bit general status and one or more 8/16-bit words of extended status.
Codes in the gray area aren't available NCW-3DNIP.
(1) General Status Code: 01h (connection failure)
Extended Status
Code (in hex)
0100
0101 - 0102
0103
0104 - 0105
0106
0107
0108
0109
010A - 010F
0110
0111
0112
0113
0114
0115
0116
0117
0118
0119
011A
011B
011C
011D
011E
011F
0120
0121
0122
0123
0124
0125
0126
Connection in use or duplicate Forward Open
Reserved
Transport Class and trigger combination not supported
Reserved
Ownership conflict
Target connection not found
Invalid network connection parameter
Invalid connection size
Reserved
Target for connection not configured
RPI not supported.
RPI value not acceptable
Out of connections
Vender ID or product code mismatch
Device type mismatch
Revision mismatch
Invalid produced or consumed application path
Invalid or inconsistent configuration application path
Non-listen only connection not opened
TARGET object out of connections
The Production Inhibit Time is greater than the RPI
Transport class not supported
Target to originator production trigger not supported
Direction not supported
Invalid originator to target network connection fixvar
Invalid target to originator network connection fixvar
Invalid originator to target network connection priority
Invalid target to originator network connection priority
Invalid originator to target network connection type
Invalid target to originator network connection type
Invalid originator to target network connection redundant_owner
Invalid configuration size
Description of Status
79
(1/3)
