Extended Status
Code (in hex)
0810 No target application data available
0811 No originator application data available
0812 Node address has changed since the network was scheduled
0813 Not configured for off-subnet multicast
0814 Invalid produce / Consume data format
0815 - FCFF Reserved
FD00 - FFFF Do not use

11-4-2. Extended status codes for protocol stack (communication control part)

The error codes indicate the response to the communication control part including CIP.
These error codes shall be used to help diagnose the problem with a Service Request.
The error code shall be split into an 8-bit general status and one or more 8-bit words of extended status.
(1) General Status Code: FBh (network action error)
Extended Status
Code (in hex)
01 CIP IO FORWARD OPEN TARGET to originator action
02 Invalid socket address
03 Invalid originator to target network parameter
04 Invalid target to originator network parameter
05 Invalid UDP port
06 Invalid multicast JOIN (invalid muticast address)
07 Unequipped CIP IO packet (lack of resource)
08 Unequipped CIP IO producer
09 Unequipped CIP IO producer
0A Lack of the CIP resource
0B CIP IO timeout action
0C CIP IO close action
0D CIP IO stop action
0E CIP adapter stop action
Description of Status
Description of Status
81
(3/3)
