Continued from the previous page
Offset Address
(Byte)
+16 UDINT
+20 UDINT
+24 WORD
+26 WORD
Size Name
Axis-2 Position
Reserved
Axis-2 Status
Axis-2 Control
Answerback
Data Format
Axis-2 Position data
Shows the Axis-2 Position data.
Reserved
Axis-2 Status
Bit
SE (Sensor Error)
0
Indicates that a SSE/SPF/DE occurred.
0: No error
1: Error
Reserved
1-4
SSE (Disconnected Sensor Error)
5
Indicates that a sensor is disconnected.
0: Connected
1: Disconnected (Error)
SPF (Sensor Circuit Power Error)
6
Indicates that the internal power supply of NCW-3DNIP is
malfunction.
0: Normal
1: Error
DE (Sensor Data Error)
7
Indicates "DE" status.
0: No error
1: Error
Reserved
8-15
Axis-2 Control Flag Answerback
Bit
Reserved
0-5
ERRCLR (Error Clear) Answerback
6
0: "ERRCLR" failed.
1: "ERRCLR" succeeded
PRESET Answerback
7
0: "PRESET" failed
1: "PRESET" succeeded.
Reserved
8-15
71
Description
Description
Description
