NSD ABSOCODER NCW-3DNIPLW Specifications & Instruction Manual page 122

ID Name
0x04 Physical Link Object
0x05 Interface Configuraton
0x06 Host Name
0x07 Safety Network Number
0x08 TTL Value
Access
Data Type
Get Set
○ Structure
－
UINT
Packed
EPATH
○ ○ Structure
UDINT
UDINT
UDINT
UDINT
UDINT
STRING
○ ○ STRING
USINT[6]
－ －
USINT
－ －
113
Description
Identifies an object (Ethernet Link Object) related to the
physical interface.
The path indicates the Instance 1 of the Ethernet Link
Object class.
Path Size 2
Path "20 F6 24 01"
NCW-3DNIP configures necessary settings as a TCP/IP
node.
Bit5 (Interface Configuration Pending) of Attribute
1(Status) will be TRUE (1) if the settings are valid.
Reset Service (0x05) of the Identify object must be
requested when activating settings.
This attribute is stored in the non-volatile memory.
IP Address IP address (host address)
*: This attribute is invalid when the IP
address is set to a value at [ADR]
rotary switch on the NCW-3DNIP
panel side except "0".
Network Mask Network mask
Gateway Gateway IP address
Address
Name Server Primary DNS server IP address
Name Server2 Secondary DNS server IP address
Domain Name "nsdcorp.co.jp" (default)
Default domain name
The name should be less than 48
characters, and a length should be
padded to the nearest even number.
(The pad is not including in the
length.)
The Domain Name is not configured
when the length is 0.
"NCW-3DNIP" (defalt)
A NCW-3DNIP host name is configured.
This attribute is stored in the non-volatile memory.
The name should be less than 64 characters, and a
length should be padded to the nearest even number.
(The pad is not including in the length.)
*:A NCW-3DNIP doesn't support the DHCP-DNS
update function.
NCW-3DNIP doesn't support this attribute.
NCW-3DNIP doesn't support this attribute.
(3/4)
