NSD ABSOCODER NCW-3DNIPLW Specifications & Instruction Manual page 57

(2) The "Select Module Type" dialog box appears
(3) Uncheck the "Module Type Vendor Filters" checkbox.
(4) Check the "NSD Corporation" checkbox.
(5) Choose NCW-3DNIP which is displayed in the "Catalog Number field".
(6) Click "Create".
(3)
(4)
(5)
(6)
(7) The "New Module" dialog box appears
(8) Choose the "General" tab.
(9) Type the name of NCW-3DNIP.
(10) Enter the IP address of NCW-3DNIP.
(11) Click "Change ..." to change the connection data size of NCW-3DNIP.
(8)
(9)
(10)
(11)
48
