NSD ABSOCODER NCW-3DNIPLW Specifications & Instruction Manual page 118

Instance Attribute (Class ID: 0x48, Instance ID: 0x01)
ID Name
0x04 DSCP Urgent
0x05 DSCP Scheduled
0x06 DSCP High
0x07 DSCP Low
0x08 DSCP Explicit
Instance Service (Class ID: 0x48, Instance ID: 0x01)
ID Name
0x0E Get_Attribute_Single
0x10 Set_Attribute_Single
Access
Data Type
Get Set
○ ○ USINT
○ ○ USINT
○ ○ USINT
○ ○ USINT
○ ○ USINT
Read out one attribute value from NCW-3DNIP.
Write one attribute value to NCW-3DNIP.
109
Description
Set the DSCP value for CIP transport class 0/1
messages with Urgent priority.
Default: 55 (110 11 1b)
This setting is invalid for NCW-3DNIP.
Set the DSCP value for CIP transport class 0/1
messages with Scheduled priority.
Default: 47 (101 11 1b)
This setting is invalid for NCW-3DNIP.
Set the DSCP value for CIP transport class 0/1
messages with High priority.
Default: 43 (101 01 1b)
This setting is for NCW-3DNIP I/O traffic.
Set the DSCP value for CIP transport class 0/1
messages with Low priority.
Default: 31 (011 11 1b)
This setting is invalid for NCW-3DNIP.
Set the DSCP value for CIP Explicit messages
(Transport Class 2/3 and UCMM).
Default: 27 (011 01 1b)
This attribute setting is for NCW-3DNIP Explicit
message traffic.
Description
