9-7. Set Parameter of NCW-3DHIP

Before NCW-3DNIP is used, parameters must be configured.
Note
In the case of using one sensor, NCW-3DNIP might not operate normally when the parameter is set by a
configuration tool except RSNetWorx manufactured by Rockwell Automation, Inc.
In this case, set "1 (disable)" to "Axis Unavailable" of the axis-2 parameter, and use the axis-1 sensor
connector (SENSOR 1).
Note
When setting parameters, switch the operation mode of the host PLC to program mode (PROG).
Cannot be set in run mode (RUN).
This operation is performed by using the PLC's configuration tool (a PLC development tool software).
*: Depending on the PLC model, this operation can also be performed by the mode selection switch on the CPU card.
