Commissioning

Not grounded machine can cause electric shock. Power outlet MUST HAVE proper grounding
•
to avoid electric shock.
• Wall receptacle MUST be installed by a qualified electrician.
If supply cord damaged, it MUST be replaced by manufacturer, service agent, or a skilled
•
person in order to avoid hazard.
• DO NOT connect the machine to voltage inverters of any kind.
• Installation, assembling, and electric connections must be performed by a qualified
technician.
3.1

Ambient requirements

This machine is designed to be operated indoors at the ambient temperature from +5 °C to
+40 °C (+41 °F to +104 °F) and relative humidity not more than 45% at 40 °C (104 °F) while
using at altitudes not exceeding 1000 m over the sea level. The temperature decreasing is
related to RH increasing, for example, 90% of RH at 20 °C (68 °F). This machine MUST NOT be
exposed to precipitations of any kind (rain, snow and so on).
It is a must to provide proper ventilation arranged in accordance with all applicable laws and
rules.
The distance to closest combustible surfaces must exceed 150 mm. It is a must to provide at
least 150 mm gap between ventilation holes on the machine and any objects.
3.2

Unpacking and installation

1. Unpack the machine carefully and keep packaging for future use.
2. Check the delivery set.
3. Remove protective film where applicable.
4. Put the machine on pedestal
5. Put conveyor inside, note the position of drive shaft sprocket on the conveyor,
see Fig. 4.
2 Shall be ordered separately.
2 RL907022. Lock swivel casters of the pedestal.
