- Page 1 OPERATING MANUAL DISPLAY WARMERS VTN SERIES (VTN-088, VTN-049, VTN-049H) CAUTION: READ THE INSTRUCTIONS BEFORE USING THE MACHINE! PDF version of this manual is available on www.robolabs.pro...
-
Page 2: Table Of Contents
tm1641 Jan-20 Table of contents Safety requirements ................... 3 1. Overview ......................4 1.1. Purpose ....................4 1.2. Technical specifications ................4 1.3. Delivery set ..................... 4 1.4. Power requirements ................4 1.5. Design and principle of operation ............5 1.6. -
Page 3: Safety Requirements
tm1641 Jan-20 Safety requirements DO NOT WASH WITH WATER! READ AND UNDERSTAND THE MANUAL BEFORE START! ONLY INSTRUCTED PERSONNEL ARE ALLOWED TO OPERATE THE EQUIPMENT! USE THE APPLIANCE FOR INTENDED PURPOSE ONLY! SOME PARTS ARE HOT WHILE IN OPERATION! BURN HAZARD! This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction... -
Page 4: Overview
tm1641 Jan-20 1. Overview 1.1. Purpose Nacho display warmers are intended to keep nacho chips at optimal temperature and to provide good appearance to the product at sales point. Warmer may fit up to 24 or 36 standard nacho trays with chips and cheese. It has internal air convective adjustable heating, inner room illumination and light boxes with NACHOS inscription on two opposite sides. -
Page 5: Design And Principle Of Operation
tm1641 Jan-20 and call for qualified electrician! Equipotential bonding wire (up to 10 sq.mm) shall be connected to screw terminal marked with IEC 5021 sign. It is necessary to check electric wires and ground connection of the machine periodically. In case of faults found, an electrician must be called. It is allowed to turn the machine on only after all the issues are resolved. -
Page 6: Intended Use
tm1641 Jan-20 2. Intended use 2.1. Operation mode Plug the warmer in the mains. Flip the main switch 1 to turn illumination, heating, and blower. Load the product inside, not more than 3 kg on each shelf. 3. Technical maintenance DISCONNECT ELECTRIC PLUG BEFORE CLEANING! DO NOT WASH ELECTRIC PARTS OF THE MACHINE WITH WATER! DO NOT USE SHARP TOOLS OR ABRASIVES FOR CLEANING! -
Page 7: Acceptance Certificate
tm1641 Jan-20 5. Acceptance certificate ACCEPTANCE CERTIFICATE _____________ _____________ Product Name Serial No. The equipment is made with accordance to mandatory requirements of the state standards, actual technical documentation, and approved for use. QC Engineer STAMP HERE _________________ _________________ Signature Full Name _________________ DD.MM.YYYY... -
Page 8: Warranty Obligations
Due to constant improvement of the equipment, technical specifications are subject to change without prior notice! 7. Manufacturer details NPO Tvertorgmash LLC 11 Industrial Street, Tver, 170000 Russia Technical support: Email: support@robolabs.pro Phone: +7 495 956 4000... -
Page 9: Annex A. Electric Components List
tm1641 Jan-20 Annex A. Electric components list SIGN PART SPECIFICATIONS ARTICLE# Thermostat TK24-00-1-110 110°C 10 A, 250 V Thermostat TK24-00-1-57 570°C 10 A, 250 V Heater 1GIK1Z159001 IRCA 600 W, 230 V Heating cable Jen-Ter 6.56 Ohm/ft EL1, EL2 Light Camelion WL-2001 8 W, 230 V Fuse S1041 10 A, 250 V...
