Introduction and General Information
Keyp@dtd cctctraisutseeecwwes
Power requirements ............
External AC adapter
Input voltage ................
FYEQUENCY .........cccseeeees
CUITEN esa uvecnevews
Output voltage...............
Environment
Operating ...........
DIOMAUE tore eeeeku ss
UMUGNY lee he ee ore ots ox
Dimensions ............
Weight
With 2 drives .......
With battery .........
With internal modem
eos eevee
eee re eee
sores eee
weer ee ee
floppy disk drives, 360K format-
ted capacity each _ drive,
48 tpi, 9 sectors/track. Write-
protection recognized. Operating
system: MS-DOS (PC-DOS com-
patible) version 1.25 and higher.
63-key QWERTY arrangement
with 4 cursor control keys. Also
included are the 10 touch control
function keys and 4 icon keys.
+12.8 VDC at 2.5 amperes (32
watts).
115 VAC (95-130 VAC); 220 VAC
(190-260 VAC); jumper selecta-
ble.
60 Hz (48-62 Hz); 50 Hz (48-62
Hz).
4 amperes maximum continu-
ous (full load, 115 _
+ 12.8 VDC.
590-90 degrees Fahrenheit (10-
32 degrees Celsius).
—40 through +125 degrees
Fahrenheit (— 40 through +51
degrees Celsius).
20-80% relative humidity (non-
condensing).
9.5" x 13.0" x 6.0" (24.1 cm
x 33.0cm x 15.2 cm) with key-
board closed. 13.4" deep (34.0
cm) with keyboard open.
14.4 Ibs. (6.54 kg).
16.0 Ibs. (7.26 kg).
14.7 Ibs. (6.67 kg).
