SSV Works X32-PHZ3V Manual page 8

E E E
E. Remove gas cover on the passenger side to expose a 10mm nut. Unscrew with a wrench and T30 torx driver.
E2 E2 E2
E2. Using panel removal tool unsnap (2) push clips on the driver and passenger side dash covers. Unscrew the (4) T30 screws on the passenger
side, and (7) T30 screws on the driver side.
F
G
F. Remove fender well panel using a T30 driver (will need a10mm socket for
G. After the fender well panel is removed, remove the third fastener clip
the screw near the headlight)
from the bottom.
8
