SSV Works X32-PHZ3V Manual page 18

UNDER SEAT SUBWOOFER ENCLOSURE (DRIVER SIDE)
THIS STEP IS OPTIONAL
Some x3 models have a thinner skid plate than others and may rattle more. We have provided a drill template to help minimize skid plate rattle.
H. To help minimize skid plate rattle, we have supplied a drill template that adds 4 holes to help relieve air pressure that is being generated by the high
output of the sub enclosure. Use the mounting bracket for the front of the sub enclosure for reference. Line up the template under the sub mounting
brackets. (1). With hole punch/scribe tool mark the 4 drilling points through the template on to the floorboard (2). Drill the four (4) - 1½" holes with a
hole saw (3).
A. Apply the short foam strips to the large bracket in the order shown above (A1).
Apply the long foam strips to the outside edges of the enclosure. (Driver outside = left /
Passenger outside = right) (A2).
18
1
A1
2
A2
