SSV WORKS, 2610 Calle Quetzal, Camarillo, CA 93012
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
5
pg
Panel
Disassembly
7
pg
Dash Speaker Panel
Installation
9
pg
JVC MR1
Installation
12
pg
Rear Cage Pod
Installation
2017-2024 Can Am Maverick X3
Maverick X3
X32-PHZ2A
Phase 2, A-Spec, 4-Speaker
Audio Kit with JVC MR1
1
Advertisement
Related Manuals for SSV Works X32-PHZ2A
Summary of Contents for SSV Works X32-PHZ2A
- Page 1 X32-PHZ2A 2017-2024 Can Am Maverick X3 Phase 2, A-Spec, 4-Speaker Audio Kit with JVC MR1 SSV WORKS, 2610 Calle Quetzal, Camarillo, CA 93012 www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751 Maverick X3 Panel Disassembly Dash Speaker Panel Installation JVC MR1...
-
Page 2: Parts List
All SSV Works enclosures are covered by a limited lifetime warranty against defects in instructions completely before material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty installation to avoid possible injury, or against defects in material or workmanship. Labor for replacement of defective components damage to the accessory or vehicle. - Page 3 All SSV Works enclosures are covered by a limited lifetime warranty against defects instructions completely before in material or workmanship. All SSV Works Electronics are covered by a limited 1 year installation to avoid possible injury, or warranty against defects in material or workmanship. Labor for replacement of defective damage to the accessory or vehicle.
- Page 4 WARRANTY INFORMATION: Please read and understand these All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or instructions completely before workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against defects in installation to avoid possible injury, or material or workmanship.
- Page 5 PANELS AND DASH DISASSEMBLY A. To remove the seat, use a 13mm socket and wrench to remove front (2) bolt and nut, and use a 18mm socket to remove (2) rear nuts and seat belt nut ( repeat on other seat) B.
- Page 6 E. Remove gas cover on the passenger side to expose a 10mm nut. Unscrew with a wrench and T30 torx driver. E2. Using panel removal tool unsnap (2) push clips on the driver and passenger side dash covers. Unscrew the (4) T30 screws on the passenger side, and (7) T30 screws on the driver side.
- Page 7 DASH SPEAKER PANEL INSTALLATION TOOLS NEEDED FOR INSTALLATION - T20 & T30 Torx Driver - 8, 10 & 13mm Socket Wrench Refer to the X3-DP6A installation manual included in the kit for a detailed installation process of the dash speaker panels. RUNNING WIRE HARNESSES JVC MR1 POWER HARNESS Connect the B-H2368 SSV to JVC adapter...
- Page 8 DASH SPEAKER PANEL AUDIO CABLES Run the B-H2368 SSV to JVC adapter harness from the JVC radio to the B-H1909 front speaker harness and plug in the dash panel speakers. REAR CAGE POD SPEAKER AUDIO CABLES Run the B-H2368 SSV to JVC adapter harness from the JVC radio to the B-H1913 and B-H1912 audio extension harness.
- Page 9 DASH KIT ASSEMBLY A. Set the base plate on the dash. Press the (4) drill guides onto the base plate B. Using a 1/8” drill bit, drill the center of the drill guides to provide C. Set aside the base plate and open the pilot holes up with a 1/4” pilot holes.
- Page 10 F. Place (4) M6 T30 screws and washers into each drilled hole. Fasten G. Using a #2 phillips screwdriver, secure the front of the base plate from the bottom a washer and M6 nut. Secure each screw with with the provided (2) #6 x ½” screws. 10mm wrench and T30 torx driver.
- Page 11 L. Secure the backside of the DMR1 with (2) push pins. M. Center the trim ring on the MR1 and firmly press down until the side and corners click into place. JVC MR1 WIRING CONNECTION A. Connect the front (white/gray) output from B.
- Page 12 REAR CAGE POD INSTALLATION A. Find the best orientation for the speaker on your bar and B. Loosely install the clamp base to the cage mount pod with the screw in the Set Screws in the OPPOSITE holes of where the two (2) M6 hex head bolts and washers, place the cage mount clamp will install into.
- Page 13 F. Route the speaker wire away from any moving parts and any sharp metal, then connect to the speaker pods. THIS CONCLUDES THE INSTALLATION PROCESS. REPLACE THE FACTORY PANELS AND SEATS. QUESTIONS? PLEASE CONTACT SSV WORKS AT 818-991-1778 OR EMAIL SUPPORT@SSVWORKS.COM...
- Page 14 © 2024 SSV Works, Camarillo, CA 93012 X32-PHZ2A 7-31-24...
