SSV Works X32-PHZ3V Manual page 13

The amp tray mounts on the driver side firewall above the tube chassis.
B. Drill a hole through the pilot holes using a 1/4" drill bit.
Be sure to move the amp plate out of the way before drilling.
D. From the outside of the firewall, use the included M6 x 16mm screw
and washer to secure the amp plate through the hole you drilled on
the firewall.
A. Make a pilot hole with a pick tool through the top right screw hole
in the amp plate and push all the way through the vehicle panel.
B
C. Secure the amp tray to the vehicle's ROPS cage using the supplied
M6 flange hex head Bolt, 10mm nut and washer.
D
E. Mount the loop clamp to the bottom tube chassis and secure it to the
amp tray using a M4 x 12mm phillips screw and washer.
A
C
E
13
