SSV Works X32-PHZ3V Manual page 19

B C
B. Using the supplied T-30 torx M6 screws and washers, screw the C. Using the supplied T-30 torx M6 screws and washers, screw the
C bracket to the bottom left side of the enclosure. Large bracket to the right side of the enclosure shown above. Do
not screw in all the way, leave the screws somewhat loose so that
you can fit the enclosure snug and then tighten the screws after.
D D
D. To remove driver the seat, use a 13mm socket and wrench to remove front (2) bolt and nut, and use a 18mm socket to remove (2) rear nuts and
(1) 16mm seat belt bolt. Disconnect the seat belt sensor.
E E E
E. Remove the factory 10mm nut and bolt from the brake line. Place the washer on top of the factory bracket and push the long M6x25mm screw through
the top. Then attach the brake line, spacer, washer and nut. (Disregard this step for the 4-seat Maverick X3 Max)
19
