SSV Works X32-PHZ3V Manual page 7

PANELS AND DASH DISASSEMBLY
A A
A. To remove the seat, use a 13mm socket and wrench to remove front (2) bolt and nut, and use a 18mm socket to remove (2) rear nuts and seat belt nut
( repeat on other seat)
B B B
B. Carefully unsnap console panels by hand or with a panel removal tool.
C
D
C. Unscrew (2) T30 torx located on the center console panel under the
D. Carefully unsnap rear cover to expose the engine compartment
dash. Use a panel tool to remove push pins on passenger side.
7
