SSV WORKS, 2610 Calle Quetzal, Camarillo, CA 93012
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
7
pg
Panel
Disassembly
9
pg
Dash Speaker Panel
Installation
11
pg
Amplifier
Installation
14
pg
JVC MR1
Installation
17
pg
Subwoofer
Installation
20
pg
Rear Cage Pod
Installation
2017-2024 Can Am Maverick X3
800W Audio Kit with JVC MR1
Maverick X3
X32-PHZ4A
Phase 4, A-Spec, 5-Speaker
1
Advertisement
Related Manuals for SSV Works X32-PHZ4A
Summary of Contents for SSV Works X32-PHZ4A
- Page 1 X32-PHZ4A 2017-2024 Can Am Maverick X3 Phase 4, A-Spec, 5-Speaker 800W Audio Kit with JVC MR1 SSV WORKS, 2610 Calle Quetzal, Camarillo, CA 93012 www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751 Maverick X3 Panel Disassembly Dash Speaker Panel Installation Amplifier...
- Page 2 All SSV Works enclosures are covered by a limited lifetime warranty against defects in instructions completely before material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty installation to avoid possible injury, or against defects in material or workmanship. Labor for replacement of defective components damage to the accessory or vehicle.
- Page 3 All SSV Works enclosures are covered by a limited lifetime warranty against defects instructions completely before in material or workmanship. All SSV Works Electronics are covered by a limited 1 year installation to avoid possible injury, or warranty against defects in material or workmanship. Labor for replacement of defective damage to the accessory or vehicle.
- Page 4 All SSV Works enclosures are covered by a limited lifetime warranty against defects in instructions completely before material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty installation to avoid possible injury, or against defects in material or workmanship. Labor for replacement of defective components damage to the accessory or vehicle.
- Page 5 All SSV Works enclosures are covered by a limited lifetime warranty against defects instructions completely before in material or workmanship. All SSV Works Electronics are covered by a limited 1 year installation to avoid possible injury, or warranty against defects in material or workmanship. Labor for replacement of defective damage to the accessory or vehicle.
- Page 6 All SSV Works enclosures are covered by a limited lifetime warranty against defects instructions completely before in material or workmanship. All SSV Works Electronics are covered by a limited 1 year installation to avoid possible injury, or warranty against defects in material or workmanship. Labor for replacement of defective damage to the accessory or vehicle.
- Page 7 PANELS AND DASH DISASSEMBLY A. To remove the seat, use a 13mm socket and wrench to remove front (2) bolt and nut, and use a 18mm socket to remove (2) rear nuts and seat belt nut ( repeat on other seat) B.
- Page 8 E. Remove gas cover on the passenger side to expose a 10mm nut. Unscrew with a wrench and T30 torx driver. E2. Using panel removal tool unsnap (2) push clips on the driver and passenger side dash covers. Unscrew the (4) T30 screws on the passenger side, and (7) T30 screws on the driver side.
- Page 9 DASH SPEAKER PANEL INSTALLATION TOOLS NEEDED FOR INSTALLATION - T20 & T30 Torx Driver - 8, 10 & 13mm Socket Wrench Refer to the X3-DP65A installation manual included in the kit for a detailed installation process of the dash speaker panels. RUNNING WIRE HARNESSES JVC MR1 POWER HARNESS Connect the B-H2368 SSV to JVC adapter...
- Page 10 AMP POWER CABLES Connect the A-H1Q power/ground wire from the amplifier to the battery. Use the provided fuse holder for circuit protection. DASH SPEAKER PANEL AUDIO CABLES Run the B-H1385 front speaker harness from 800.5 amplifier to the dash speaker panels. The shorter end of the harness goes to the driver side dash speaker panel.
- Page 11 SUBWOOFER AUDIO CABLE Run the B-H2702 Subwoofer extension cable from 800.5 amplifier to the subwoofer. The subwooder enclosure is mounted under the driver seat. AMP INSTALLATION B-H2605 8005 Amplifier Harness 1. INPUT (FRONT) - CONNECT TO JVC MR1 “FRONT SPEAKERS” 2.
- Page 12 C. Secure the amp tray using the supplied M6 flange hex head Bolt, D. Make a pilot hole with a pick tool through the top right screw hole 10mm nut and washer to the ROPS base. in the amp plate and push all the way through the vehicle panel. F.
- Page 13 F. Route the front speaker harness (B-H1385) towards the driver and passenger side of the vehicle and plug in the 4 pin audio connector to the 800.5 amplifier front outputs. CONNECTING POWER & GROUND CABLE TO BATTERY Battery Terminal Cable Power Wire Break...
- Page 14 DASH KIT ASSEMBLY A. Set the base plate on the dash. Press the (4) drill guides onto the base plate B. Using a 1/8” drill bit, drill the center of the drill guides to provide C. Set aside the base plate and open the pilot holes up with a 1/4” pilot holes.
- Page 15 F. Place (4) M6 T30 screws and washers into each drilled hole. Fasten G. Using a #2 phillips screwdriver, secure the front of the base plate from the bottom a washer and M6 nut. Secure each screw with with the provided (2) #6 x ½” screws. 10mm wrench and T30 torx driver.
- Page 16 L. Secure the backside of the DMR1 with (2) push pins. M. Center the trim ring on the MR1 and firmly press down until the side and corners click into place. JVC MR1 WIRING CONNECTION To Amp To Amp Subwoofer Input Rear Input To Radio Rear Output...
- Page 17 UNDER SEAT SUBWOOFER ENCLOSURE (DRIVER SIDE) THIS STEP IS OPTIONAL Some x3 models have a thinner skid plate than others and may rattle more. We have provided a drill template to help minimize skid plate rattle. H. To help minimize skid plate rattle, we have supplied a drill template that adds 4 holes to help relieve air pressure that is being generated by the high output of the sub enclosure.
- Page 18 B. Using the supplied T-30 torx M6 screws and washers, screw the C. Using the supplied T-30 torx M6 screws and washers, screw the C bracket to the bottom left side of the enclosure. Large bracket to the right side of the enclosure shown above. Do not screw in all the way, leave the screws somewhat loose so that you can fit the enclosure snug and then tighten the screws after.
- Page 19 F. Remove the seat mounting spacer from the seat mounting stud G. Replace the factory seat bolt spacer with the supplied SSV towards the center of the car. Works spacer on top of bracket C. Feed the enclosure down under the seat bar and simultaneously guide “Bracket C”...
- Page 20 I. The large bracket will align over (2) factory holes in the chassis. Using a #3 Phillips screwdriver, secure the large bracket to the chassis with the provided (2) thread rolling screws and washers. J. Route the B-H2702 sub extension harness along the center console away from any moving parts and sharp metal towards the rear of the vehicle then connect to the X32-DUS10 (driver side).
- Page 21 C. Place both ring mounting clamps on the cage using the plastic bag to prevent scratching, place the cage mount pod in its final mounting location and secure to the clamps using the two (2) M6 allen socket head bolts and washers with a 5mm allen key. PLACEMENT OF THE POD DEPENDS ON WHAT TYPE OF ROLL CAGE YOU HAVE (FACTORY OR AFTERMARKET) AND YOUR PREFERENCE OF WHERE YOU WANT THE PODS TO BE INSTALLED.
- Page 22 F. Route the speaker wire away from any moving parts and any sharp metal, then connect to the speaker pods. THIS CONCLUDES THE INSTALLATION PROCESS. REPLACE THE FACTORY PANELS AND SEATS. QUESTIONS? PLEASE CONTACT SSV WORKS AT 818-991-1778 OR EMAIL SUPPORT@SSVWORKS.COM...
- Page 23 © 2024 SSV Works, Camarillo, CA 93012 X32-PHZ4A 7-31-24...
