Front Speaker Kick Pod Add-On Kit
Installation
5
pg
Front Kick Panel Speaker
Wiring Diagram
X32-PHZ+FK
2017-2024 Plug-&-Play Front Kick
SSV Can Am Maverick X3 Audio Kits
Maverick X3
Speaker Pods Add-On Kit for
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SSV Works X32-PHZ+FK
Summary of Contents for SSV Works X32-PHZ+FK
- Page 1 X32-PHZ+FK 2017-2024 Plug-&-Play Front Kick Speaker Pods Add-On Kit for SSV Can Am Maverick X3 Audio Kits SSV WORKS, 2610 Calle Quetzal, Camarillo, CA 93012 www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751 Maverick X3 Front Speaker Kick Pod Add-On Kit...
- Page 2 All SSV Works enclosures are covered by a limited lifetime warranty against instructions completely before defects in material or workmanship. All SSV Works Electronics are covered by a installation to avoid possible injury, or limited 1 year warranty against defects in material or workmanship. All SSV Works damage to the accessory or vehicle.
- Page 3 FRONT KICK PODS ADD-ON KIT INSTALLATION A. Remove the eleven (11) T30 Torx bolts that secure the fender. B. Cut out the template (Driver/Passenger) along the cut line. Note: There is three (3) T30 screws on passenger side and Position the template on inner plastic ,making sure to square two (2) on driver side that will have a 10mm bolt.
- Page 4 G. Route speaker connector through the 1/2” hole that was K. Place the kick pod in position for mounting. Use the provided drilled out. M6 screws and washers to hand tighten the pod to the kick panel. L. Once all screws have been inserted into pod , tighten all three M.
- Page 5 FRONT KICK PODS ADD-ON KIT WIRING DIAGRAM Description Part # Speaker “Y” Harness B-H1463 RGB “Y” Splitter B-H3072 Front Speaker Harness (48”) B-H1909 RGB Speaker Harness (48”) B-H2935 Detail Description Connect Front Output from B-H2605 to B-H1463 Connect LIT-CC Output to B-H3072 Connect to Dash Speaker Panel Harness Connect to B-H1909 for Front Kick Pods Connect to B-H2935 for Front Kick Pods RGB Speakers...
