How to replace the ink cartridge
To get the most out of your iX-1, visit our how to video hub at
or login to Myquadient to access the iX-1 user guide.
1
Activate ink cartridge replacement
Can Letter
$ 00.00
No Options
Press the key.
2024.02.03
Mem:
Next, press the scroll up button
Acct: 00000
to select ink cartridge, then
press .
1 2 3
ABC
4 5 6
Press to move the
GHI JKL
current ink cartridge into the
7 8 9
PQRS TUV
replacement position.
.
C 0
2
Remove the old ink cartridge
Open the front cover, then open
the ink cartridge slot by pulling
the blue lever toward you and
pushing it to the right.
Pull the cartridge towards
you to disengage it.
3
Unpack the new ink cartridge
Remove the cartridge from
the packaging and remove the
protective film from the print
head.
Insert the old cartridge into the
replacement cartridge packaging.
Apply the recycling label and
postage to the outside of the box
and return to Quadient.
4
Install new the ink cartridge
Insert the ink cartridge, then
turn the blue lever back to
the left until the cartridge is
secured and close the cover.
Need help? Contact us at: myquadient.ca or call 1.800.661.0200
Main Menu
0 g
9. E-Services
11. User Preferences
12. Ink Cartridge
13. Supervisor
DEF
Ink Cartidge
MNO
1. Ink Cartridge Information
WXYZ
2. Cleaning Process
3. Ink Cartridge replace...
# /:
c
c
c
kb.quadient.ca/iX-1_videos
5
Confirm ink cartridge installation
Return to the iX-1 control panel
and press .
Press to return to the
home screen.
6
Test ink cartridge alignment
Press the key.
Can Letter
Press the scroll up button to select
No Options
supervisor, then press
2024.02.03
Mem:
Acct: 00000
Enter the supervisor PIN code
09430 and press .
Can Letter
The supervisor main menu will
$ 00.00
No Options
appear. 1 2
ABC
2024.02.03
4 5
GHI JKL
Mem:
Acct: 00000
7 8
Press , the maintenance
PQRS TUV
screen will appear.
C 0
Can Letter
$ 00.00
1 2 3
Next, press .
No Options
ABC DEF
0 g
4 5 6
2024.02.03
GHI JKL MNO
Mem:
7 8 9
PQRS TUV WXYZ
Acct: 00000
.
C 0
# /:
1 2 3
Press to initiate ink
ABC DEF
cartridge alignment process.
4 5 6
GHI JKL MNO
7 8 9
PQRS TUV WXYZ
.
C 0
#/ :
Insert an envelope into the
printing path to complete a test
print or press to quit.
7
Align the ink cartridge
From the pattern printed, choose
the letter where the top and
bottom lines are most closely
aligned.
In this example, F would be
selected, but it may be a different
letter for your iX-1.
Using the up and down arrow
buttons, select the letter and
press to complete the
alignment process.
10
p
Main Menu
9. E-Services
$ 00.00
11. User Preferences
.
0 g
12. Ink Cartridge
13. Supervisor
3
Supervisor Menu
0 g
DEF
4. Impression Memory
6
MNO
5. Account management
9
6. System settings
WXYZ
7. Maintenance
.
# /:
Ink Cartridge
1. Ink information
2. Cleaning Process
3. Cartridge Alignment
4. Ink Cartridge repla...
