quadient iX-1 Series Replacement Manual

iX-1 Series
LAN Adapter & Cable Replacement Guide
For more information or if you experience any issues please visit :
kb.quadient.us/iX-1
The LAN adapter and LAN cable provide communication between the iX-1 postage meter and the
online server using a high speed internet or LAN (Local Area Network) connection. The following
steps will guide you through the removal of the LAN adapter and LAN cable and the installation of
the replacement parts.
Shipping Package Contents
1 - LAN Adapter
1 - Prepaid Shipping Label
Replacing The LAN Adapter & LAN Cable
1
Esure the machine is in
sleep mode. The power
indicator light will be amber.
2
Disconnect the power
cable from the wall
outlet. This will turn off the
iX-1 postage meter.
3
Disconnect the old LAN
cable from the LAN
wall outlet or router.
1 - LAN Cable
4
adapter from the iX-1
postage meter.
5
6
package with packing tape (not provided). Apply
the prepaid label to the package over the old
shipping label.
LAN Adapter & LAN Cable Components
LAN
Adapter
LAN
Cable
Disconnect the USB
cable on the old LAN
Remove the new LAN adapter, LAN cable, and
shipping label from the shipping package.
Place the old LAN adapter and LAN cable
into the same shipping package. Seal the
LAN Wall
Outlet
OR
Router
