quadient iX-1 Series Replace

How to replace your iX-1
Because the iX-1 is so reliable, we can fix most problems over the phone.
If we cannot fix your problem, we will send a replacement system. Once you receive your
replacement system, complete the steps below to replace and return your damaged system.
a
iX-1 franking
machine
Note: Perform "Upload Statistics" and "Save Customer Data". Refer User Guide for more information.
1
Activate cartridge replacement
1st Inl Lett
£ 000.00
No services
0 g
Press the key.
01.02.23
Mem:
Next, press the scroll up button Acct: 00000
to select cartridge, then press .
1 2 3
Press to move the
ABC DEF
current cartridge into the
4 5 6
GHI JKL MNO
replacement position.
7 8 9
PQRS TUV WXYZ
.
C 0
# / :
2
Remove the cartridge
Open the front cover, then
pull on the left side of the
blue lever to unlock the
cartridge.
Pull the cartridge towards
you to disengage it.
3
Disconnect the power cable
Unplug the power adapter
cable connector from the
back of your iX-1.
4
Disconnect the Weighing Platform
Unplug the weighing platform
connector from the scale port
located on the back of the iX-1.
Remove the weighing plat-
form (d) from the mailing
system (a).
3
Need help? Contact us at: www.myquadient.co.uk or call 0845 8800000
c
b
Postage Cartridge
meter
Main Menu
9. Online Services
10. User Preferences
11. Cartridge
13. Supervisor
Cartridge
1. Ink information
2. Cleaning Process
3. Headset replacement
c
2
1
a
4
d
Weighing
platform
5
Disconnect the internet cable
Unplug the LAN cable from
the internet cable port
located on the of the iX-1 (e).
6
Remove the meter
Turn the iX-1 on its back and
open the meter cover located
on the bottom of the system.
Remove the meter
close the cover.
7
Unpack the box
Remove the replacement unit
from the box and place the
f
original unit into the box to
return.
8
Remove print head packaging
Open the front cover.
Remove the protective
packag ing, then close the
front cover.
d
1
e f
LAN Power adapter
cable and cable
e
(b) and
2
1
4
3
b
a
