IN485FGL001I000 Gateway
3. Quickstart Guide for the IN485FGL001I000 Gateway
IMPORTANT
Disconnect all systems from power before connecting them to the gateway.
1.
Mount the gateway in the desired installation site. This gateway can be mounted over a DIN rail, a wall, or
inside the indoor unit (in some indoor unit models only). See details in
NOTE
DIN rail mounting inside a grounded cabinet or metal enclosure is recommended.
2.
Connect the gateway to the BACnet/Modbus network via its EIA-485 port.
3.
Connect the gateway to the indoor unit using the supplied AC connection cable. See details in
Procedure (page
8).
4.
Configure the gateway using the built-in DIP switches. See details in
NOTE
Use the SW1-5 (DIP switch 1, position 5) to set the gateway as a BACnet or Modbus server
device:
• BACnet MS/TP: Position 5 is off (down). This is the default setting.
• Modbus RTU: Position 5 is on (up).
5.
Check the communication performance between the BACnet/Modbus bus and the AC system through the
gateway's LED indicators. See details in
6.
The Intesis gateway is ready to be used in your system.
Page 4 of 74
LED Indicators (page
12).
Quickstart Guide for the IN485FGL001I000 Gateway
Mounting (page
7).
Connection
DIP switches (page
9).
USER MANUAL Version 1.0.9
