IN485FGL001I000 Gateway
Register Name
ERROR CODE
OPEN WINDOW TIMEOUT (MIN)
NOTE
Once window contact is "open",
this is the time in minutes before
turning the AC unit off.
BAUDRATE
MODBUS SLAVE ADDRESS
MAX NUM OF FANSPEEDS
INPUT SENSOR TEMPERATURE
NOTE
Ambient temperature provided by
a sensor from the Modbus side.
See Virtual Temperature Function
(page 66).
IMPORTANT
This register has no effect when
using a communication accessory
to connect the gateway and the
Fujitsu AC unit.
AC REAL SETPOINT
NOTE
Temperature setpoint sent to the
indoor unit. To know more, see
Considerations on Temperature
Signals (page 67).
ACTUAL AC MAX SETPOINT
Page 62 of 74
Possible values
0: No error present
65535 (-1 if it is read as a signed value): Communication
error between the gateway or the remote controller and
the AC unit.
For any other value, see Error Codes (page
0 .. 30 minutes
Default value: 30
Baudrate currently selected via DIP switch SW2.
1 .. 63
Configured number of fan speeds.
0x8000 (-32768): Initialization value. No temperature is
provided by an external sensor.
Any other value: Ambient temperature reported by the
Modbus sensor.
Value in °C; °F; x1; x10
NOTE
Set the temperature units via the DIP
switch SW2.
NOTE
The value range depend on the AC
model.
-32768 (Initialization value)
Value in °C; °F; x1; x10
NOTE
Set the temperature units via the DIP
switch SW2.
NOTE
The value range depend on the AC
model.
Modbus Registers
Modbus PLC
address address
(base 0) (base 1)
11 12
70).
13 14
14 15
15 16
21 22
22 23
23 24
24 25
USER MANUAL Version 1.0.9
R/W
R
R/W
R
R
R
R/W
R
R
