7.1.3.8. Setpoint_command (Analog Output Object Type)

It is used to request a temperature setpoint from the BACnet side.
NOTE
To know more, see
Property Identifier Property Datatype
Object_Identifier BACnetObjectIdentifier
Object_Name CharacterString
Object_Type BACnetObjectType
Present_Value REAL
Status_Flags BACnetStatusFlags
Event_State BACnetEventState
Reliability BACnetReliability
Out_Of_Service BOOLEAN
Update_Interval Unsigned
Units BACnetEngineeringUnits
Min_Pres_Value REAL
Max_Pres_Value REAL
Resolution R
COV_Increment REAL
Priority_Array BACnetPriorityArray
Relinquish_Default Unsigned
Time_Delay Unsigned
Notification_Class Unsigned
High_Limit REAL
Low_Limit REAL
Deadband REAL
Limit_Enable BACnetLimitEnable
Event_Enable BACnetEventTransitionBits
Acked_Transitions BACnetEventTransitionBits
Notify_Type BACnetNotifyType
Event_Time_Stamps BACnetArray[N] of BACnetTimeStamp
Profile_Name CharacterString
NOTE
You can set the temperature scale in Celsius or Fahrenheit via the DIP switches. More information in
DIP switches (page
USER MANUAL Version 1.0.9
Considerations on Temperature Signals (page
Value
(Analog Output, 0)
SetPoint_command
ANALOG_OUTPUT (1)
If freeze protection is off: 16 .. 30°C / 61 .. 86°F
If freeze protection is on: 8 .. 10°C / 46 .. 50°F
{FALSE, FALSE, FALSE, FALSE}
STATE_NORMAL (0)
NO_FAULT_DETECTED (0)
FALSE
-
Celsius degrees (62)
Fahrenheit degrees (64)
If freeze protection is off: 16°C / 61°F
If freeze protection is on: 8°C / 46°F
If freeze protection is off: 30°C / 86°F
If freeze protection is on: 10°C / 50°F
-
0
BACnetPriorityArray
22
-
-
-
-
-
-
-
-
-
-
-
9).
IN485FGL001I000 Gateway
67).
ASHRAE
R
R
R
W
R
R
O
R
O
R
O
O
O
O
R
R
O
O
O
O
O
O
O
O
O
O
O
Gateway
R
R
R
W
R
R
R
R
-
R
R
R
-
W
R
R
-
-
-
-
-
-
-
-
-
-
-
