7.1.3.5. Mode_command (Multistate Output Object Type)

It sets the AC indoor unit's mode.
Property Identifier Property Datatype
Object_Identifier BACnetObjectIdentifier
Object_Name CharacterString
Object_Type BACnetObjectType
Present_Value Unsigned
Description CharacterString
Device_Type CharacterString
Status_Flags BACnetStatusFlags
Event_State BACnetEventState
Reliability BACnetReliability
Out_Of_Service BOOLEAN
Number_Of_States Unsigned
State_Text BACnetArray[N] of CharacterString
Priority_Array BACnetPriorityArray
Relinquish_Default Unsigned
Time_Delay Unsigned
Notification_Class Unsigned
Feedback_Value Unsigned
Event_Enable BACnetEventTransitionBits
Acked_Transitions BACnetEventTransitionBits
Notify_Type BACnetNotifyType
Event_Time_Stamps BACnetArray[N] of BACnetTimeStamp
Profile_Name CharacterString
Table 6. Mode command
Present_Value
1
2
3
4
5
NOTE
When setting the control mode in Auto, the AC unit itself decides the appropriate mode.
