Modbus Registers
Register Name
ACTUAL AC MIN SETPOINT
VANE L/R POSITION
WINDOW CONTACT FUNCTIONAL STATUS
(FEEDBACK)
EXTERNAL ON/OFF DISABLEMENT
WIN CONTACT ON/OFF DISABLEMENT
FILTER RESET
FILTER STATUS
SWITCH VALUE
ANTIFREEZE OPERATION
ECO MODE
ECONOMY OPERATION
INPUT REFERENCE TEMPERATURE (FEEDBACK)
RETURN PATH TEMPERATURE
FW version MSB
FW version LSB
RESET
USER MANUAL Version 1.0.9
Possible values
-32768 (Initialization value)
Value in °C; °F; x1; x10
NOTE
Set the temperature units via the DIP
switch SW2.
NOTE
The value range depend on the AC
model.
0: Auto
1 .. 5: Pos 1 .. Pos 5
10: Swing
NOTE
The available vane L/R positions depend
on the AC model.
0: Not active (default)
1: Active (the window is open)
0: Not active (default)
1: Active
0: Window contact is not disabling On/Off
1: Window contact is disabling On/Off
1: Reset
0: Off - Filter status clean
1: Filter status alarm
Current value of DIP switches
0: Off
1: On
0: Off
1: Econavi
2: Auto comfort
0: Disabled
1: Enabled
Value in °C; °F; x1; x10
NOTE
Set the temperature units via the DIP
switch SW2.
Value in °C; °F; x1; x10
NOTE
Set the temperature units via the DIP
switch SW2.
It shows the first two numbers of the firmware version.
Example: For version 1.2.3.4, it will show 1.2 (in
hexadecimal).
It shows the last two numbers of the firmware version.
Example: For version 1.2.3.4, it will show 3.4 (in
hexadecimal).
1: Reset
IN485FGL001I000 Gateway
Modbus
PLC
address
address
R/W
(base 0)
(base 1)
25
26
R
26
27
R/W
31
32
R
36
37
R/W
40
41
R
43
44
W
44
45
R
48
49
R
56
57
R/W
57
58
R/W
64
65
R/W
65
66
R
66
67
R
94
95
R
95
96
R
99
100
W
