7.1.3.4. Mode_status (Multistate Input Object Type)

It indicates the indoor unit's current mode.
Property Identifier Property Datatype
Object_Identifier BACnetObjectIdentifier
Object_Name CharacterString
Object_Type BACnetObjectType
Present_Value Unsigned
Description CharacterString
Device_Type CharacterString
Status_Flags BACnetStatusFlags
Event_State BACnetEventState
Reliability BACnetReliability
Out_Of_Service BOOLEAN
Number_Of_States Unsigned
State_Text BACnetArray[N] of CharacterString
Time_Delay Unsigned
Notification_Class Unsigned
Alarm_Values List of Unsigned
Fault_Values List of Unsigned
Event_Enable BACnetEventTransitionBits
Acked_Transitions BACnetEventTransitionBits
Notify_Type BACnetNotifyType
Event_Time_Stamps BACnetArray[N] of BACnetTimeStamp
Profile_Name CharacterString
Table 5. Mode status
Present_Value
1
2
3
4
5
NOTE
When setting the control mode in Auto, the AC unit itself decides the appropriate mode.
USER MANUAL Version 1.0.9
Value
(Multistate Input, 0)
Mode_status
MULTISTATE_INPUT (13)
1 .. 5
-
-
{FALSE, FALSE/TRUE, FALSE, FALSE}
STATE_NORMAL (0)
NO_FAULT_DETECTED (0), UNRELIABLE_OTHER(7)
FALSE
5
Check the Mode status table below.
-
-
-
-
-
-
-
-
-
State_Text
Heat
Cool
Fan
Dry
Auto
IN485FGL001I000 Gateway
ASHRAE Gateway
R R
R R
R R
R R
O -
O -
R R
R R
O R
R R
R R
O R
O -
O -
O -
O -
O -
O -
O -
O -
O -
