7.1.3.7. UserSetpoint_status (Analog Input Object Type)

It reports the value written in the Setpoint_command object.
NOTE
To know more, see
Property Identifier Property Datatype
Object_Identifier BACnetObjectIdentifier
Object_Name CharacterString
Object_Type BACnetObjectType
Present_Value REAL
Description CharacterString
Device_Type CharacterString
Status_Flags BACnetStatusFlags
Event_State BACnetEventState
Reliability BACnetReliability
Out_Of_Service BOOLEAN
Update_Interval Unsigned
Units BACnetEngineeringUnits
Min_Pres_Value REAL
Max_Pres_Value REAL
Resolution REAL
COV_Increment REAL
Time_Delay Unsigned
Notification_Class Unsigned
High_Limit REAL
Low_Limit REAL
Deadband REAL
Limit_Enable BACnetLimitEnable
Event_Enable BACnetEventTransitionBits
Acked_Transitions BACnetEventTransitionBits
Notify_Type BACnetNotifyType
Event_Time_Stamps BACnetArray[N] of BACnetTimeStamp
Profile_Name CharacterString
NOTE
You can set the temperature scale in Celsius or Fahrenheit scale via DIP switches. More information
in DIP switches (page
Page 24 of 74
Considerations on Temperature Signals (page
Value
(Analog Input, 17)
UserSetPoint_status
ANALOG_INPUT (0)
If freeze protection is off: 16 .. 30°C / 61 .. 86°F
If freeze protection is on: 8 .. 10°C / 46 .. 50°F
-
-
{FALSE, FALSE, FALSE, FALSE}
STATE_NORMAL (0)
NO_FAULT_DETECTED (0)
UNRELIABLE_OTHER (7)
FALSE
300
Celsius degrees (62)
Farenheit degrees (64)
If freeze protection is off: 16°C / 61°F
If freeze protection is on: 8°C / 46°F
If freeze protection is off: 30°C / 86°F
If freeze protection is on: 10°C / 50°F
-
0
-
-
-
-
-
-
-
-
-
-
-
9).
67).
ASHRAE
R
R
R
R
O
O
R
R
O
R
O
R
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
