7.1.3. Objects and Properties

7.1.3.1. Fujitsu AC Gateway (Device Object Type)

Object_Identifier: The gateway can be identified in the BACnet network automatically or manually:
• Automatic addressing (default): This mode uses a base address of 246000 + the MAC address number
selected in the DIP switch SW2.
• Manual addressing: The gateway switches to this mode when this property receives a value from the BACnet
side.
IMPORTANT
During the manual addressing mode, the gateway will not consider the MAC address configured
with the DIP switch SW2.
IMPORTANT
If the Object_Identifier is overwritten from the BACnet side, the DIP switch SW2 configuration
will not be considered for the Device instance calculation until the gateway is reset to the factory
settings. See Restore the Factory Settings (page
Object_name: In the Device Object, is configurable writing directly on this property.
Description: In the Device Object, is configurable writing directly on the property. Max. length: 63 characters.
Property Identifier
Object_Identifier
Object_Name
Object_Type
System_Status
Vendor_Name
Vendor_Identifier
Model_Name
Firmware_Revision
Application_Software_Version
Location
Description
Protocol_Version
Protocol_Revision
Protocol_Services_Supported
Protocol_Object_Types_Supported
Object_List
Structured_Object_List
Max_APDU_Length_Accepted
Segmentation_Supported
Max_Segments_accepted
VT_Classes_Supported
Active_VT_Sessions
Local_Date
Local_Time
UTC_Offset
USER MANUAL Version 1.0.9
14).
Property Datatype
BACnetObjectIdentifier
CharacterString
BACnetObjectType
BACnetDeviceStatus
CharacterString
Unsigned16
CharacterString
CharacterString
CharacterString
CharacterString
CharacterString
Unsigned
Unsigned
BACnetServiceSupported
BACnetObjectTypes Supported
BACnetArray[N] of
BACnetObjectIdentifier
BACnetArray[N] of
BACnetObjectIdentifier
Unsigned
BACnetSegmentation
Unsigned
List of BACnetVTClass
List of BACnetVTSession
Date
Time
INTEGER
IN485FGL001I000 Gateway
Value
Device, 246000 (default value)
IN485FGL001I000
DEVICE (8) (Device Object Type)
OPERATIONAL (0)
HMS Industrial Networks SLU
246
IN485FGL001I000
1.0.0.0
1.0.0.0
""
Fujitsu AC interface
1
12
-
Refer to section Supported Object
Types (page 15)
BACnetARRAY[N]
-
480
SEGMENTED-BOTH (0)
16
-
-
-
-
-
ASHRAE Gateway
R W
R W
R R
R R
R R
R R
R R
R R
R R
O -
O W
R R
R R
R R
R R
R R
O -
R R
R R
O R
O -
O -
O -
O -
O -
