Source Audio ARTIFAKT Lo-Fi Elements User Manual page 38

TRS Adaptor
Artifakt utilizes "Type A" convention for its 3.5mm TRS MIDI Input and Throughput. If you
are using DIN-TRS adaptors, make sure they are Type A and not Type B.
Can I use Artifakt in my amp's effects loop?
Artifakt's audio inputs can handle up to 8.76 dBu or 6.0 Volts peak-to-peak, which allows it
to work in most amp effects loops. Be sure to check your amp's documentation to verify
that the maximum send level is less than Artifakt's maximum input level.
How do I update the firmware?
Firmware updates are available via the Neuro Desktop Editor using the USB port. Power
the pedal and connect it to your computer using a USB-C cable. The Neuro Desktop Editor
is available from Source Audio's website:
http://www.sourceaudio.net/editorsandfirmware.html. While the pedal is connected, right-
click on the Artifakt icon in the left margin, then select "Firmware Update" from the
resulting menu.
Mac isn't letting me download the Neuro 3 software?
Mac users may see this warning message when trying to open the Neuro Desktop
software: "App can't be opened because it was not downloaded from the Mac App Store."
In order to run the Neuro Desktop, please refer to the steps in this Apple support article:
https://support.apple.com/en-us/HT202491.
Mac users may also get the warning "App cannot be opened because it cannot be
checked for malicious software". If this message pops up after downloading & attempting
to open Neuro for the first time, make sure to click "Show in Finder". This will bring you to
Neuro's location in your directory. Then, CTRL + Click "Open" from the resulting menu to
open the Neuro app. You will get the warning once more, but this time, there will be an
"Open" button. Hit Open and you will be good to go.
Rubber Feet
The Artifakt comes standard with a flat aluminum bottom, making it easy to apply Velcro
and mount to a pedalboard. Additionally, adhesive rubber feet are included in the Artifakt
box. Applying the rubber feet to the Artifakt can help prevent it from sliding on flat
surfaces such as a hardwood floor or a desktop.
Removing rubber feet is fairly easy as they can be peeled off without much issue if you
decide you don't want them. Please contact us at
like a new set of rubber feet.
Source Audio Artifakt Lo-Fi Elements User Guide
contact@sourceaudio.net if you would
