CRUSH
This engine features the core bit-crushing effects: Bit-depth Quantizing and Sample Rate
Reduction, all voiced with our Moog-style Ladder lowpass on the FILTER knob. Use the
BANDWIDTH toggle for further voicing options. The Option footswitch enables/disables a
chorusing effect for some added animation.
DESTRUCT: Adjusts the bit quantization, which increases in severity when the DESTRUCT
knob is turned from left to right.
VARY: Adjusts the sample rate reduction, from left (maximum SRR) to right (maximum
sampling rate).
FILTER: Adjusts the center-point frequency of the ladder LPF, which is fully closed when
FILTER is turned all the way to the right, and fully open (no audible filtering) when Filter is
turned to the left.
Bandwidth Switch: Limits the frequency response, altering the overall voicing of the
effect. Right = full bandwidth (no limiting), Center = some high-cut & low-cut, Left =
extreme high-cut & low-cut.
OPTION Footswitch: Tap to switch the Chorus effect ON/OFF.
LADDER
Our R-2R Ladder filter in full regalia. Adjust the frequency with the FILTER knob and
resonance (Q) with the BANDWIDTH toggle. The Ladder filter can be modulated in two
different ways:
1. Use the VARY knob for envelope effects. Turn the VARY knob clockwise for positive
motion on the filter (low to high), and counterclockwise to reverse the direction from high
to low. Center the knob for no envelope control.
2. Use the MOD controls for low frequency oscillator (LFO) control of the filter. Adjust the
waveform with the SHAPE control.
DESTRUCT: Adds an asymmetric distortion to the dry signal.
