Chapter 5 System Operation

5.3.22 Initial Setting Screen 7

No. Item
Allows the selection of alarm signals for contact
signal.
1 OUT
(See "8.1.7
details.)
Allows the selection either TEMP READY or AUTO
PURGE signal.(Output for pin No. 8 of "8.1.6
2 E_OUT
Communication Specifications
See communication specification for details.
5.3 Operation Screen
5-24
1
2
Fig. 5-25 Initial Setting Screen 7
Table 5-22 「Initial Setting Screen 7」
Descriptions
Alarm Signal Selection
【Tips】
See "8.5 BAND/READY"(page 8-16) for TEMP BAND, READY TIME (*1).
[▲] or [▼] key is used for selecting "Item" and move to other Initial
Setting Screens. And pressing the [ENT] key enabling to select the
setting or set value.
POWER ON
" (page 8-10) for
" (page 8-7).
Factory
Setting Range
Default
N/A
ALARM01 to 32
N/A
※1
TEMP READY
AUTO PURGE
HRZF Series
N/A
N/A
