1.4 Hazard Warning Label
The hazard warning labels are applied to the sections of this system where potential hazards
are present during system operation and maintenance.
The hazard warning labels are in appropriate sizes and colors to get attention of the operator.
They contain symbols in addition to the descriptions of warnings.
1.4.1 Type of Hazard Warning Label
The hazard warning labels affixed on this system are listed below.
◼ Labels of High Voltage Hazard
[High Voltage Hazard]
This warning label is affixed on the part isolated with the cover panel of the system
panel in which high voltage is applied. Do not remove cover panels that are not
designated in this manual.
Fig.1-1 Hazard Warning
Label No.1
◼ Labels of Hot/Cold Surface Hazard
[Hot/Cold Surface Hazard]
This warning label is affixed on the surface that is at high or low temperatures carrying
potential burns (or frostbite) if touched. Residual heat may cause burns despite the
power being turned OFF. Be sure of the surface reaching room temperature before work.
Fig.1-4
HRZF Series
Fig.1-2 Hazard Warning
Label No.2
Hazard Warning Label No.4
Fig.1-3 Hazard Warning
Label No.3
Fig.1-5 Hazard Warning Label No.5
